Standard configuration:
1.Double cylinders control ram moving upward and downward.
2.Right-and-lift balance achieved by torsion synchronization.
3.NOK Japan layer seals for main cylinders.
4.Schneider key electrics.
5.Upper tools fast clamps.
6.Standard front supports arms.
7.Main Motor:Siemens.
8.Oil pump:SUNNY,America.
9.Hydraulic system:Rexroth,Germany
10.Clip-and -sleeve pipe system.
11.The standard press brake three fingers of back-gauge
12.Electrical cabinet with ABB switch power outage.
13.Backgauge and Stroke Servo motor ,Taiwan Delta.
14.Ball screw and linear guider ,Taiwan HIWIN
15.Controller Estun E300
16.With safety side door and back doors.
Parameters:
No | Name | WC67Y-160/3200 |
1 | Nominal pressure | 1600 KN |
2 | Working table length | 3200 mm |
3 | Distance between uprights | 600 mm |
4 | Ram stroke | 200 mm |
5 | Max.opening height | 460mm |
6 | Throat depth | 320mm |
7 | Approaching speed | 80 mm/s |
8 | Working speed | 8-12 mm/s |
9 | Returning speed | 70 mm/s |
10 | Main Motor power | 11kw |
11 | Overall dim. (L*W*H） | 3300*1700*2700mm |
12 | Weight | 10,500 KGS |
