10 Series Hydraulic Precision Leveler
Table for Leveled Width Range of 10 Series (Material Q235/Yield Strength 235Mpa)
Roller Diameter | Φ10 | mm |
Width | 160,300,500 | mm |
Roller number | 31 | mm |
Rated Plate Thickness(Q235) | 0.1-0.3 | mm |
Max Plate Thickness (Q235) | 0.8 | mm |
Least Length | 20 | mm |
Leveled speed | 0-10 | m/min |
Leveled Precision(GB/T1184-1996) | H | |
Application Object | Foil Material |
Thickness\Width | 10-160-31 | 10-300-31 | 10-500-31 |
0.1-0.3 | 160 | 300 | 500 |
0.4 | 120 | 225 | 375 |
0.6 | 80 | 150 | 250 |
0.8 | 60 | 110 | 180 |
16 Series Hydraulic Precision Leveler
Table for Leveled Width Range of 16 Series (Material Q235/Yield Strength 235Mpa)
Roller Diameter | Φ16 | mm |
Width | 160,300,500 | mm |
Roller number | 31 | mm |
Rated Plate Thickness(Q235) | 0.2-0.6 | mm |
Max Plate Thickness (Q235) | 1.2 | mm |
Least Length | 32 | mm |
Leveled speed | 0-10 | m/min |
Leveled Precision(GB/T1184-1996) | H | |
Application Object | Tape coiling,sheet metals,flat parts,mirror sheet metals,etc |
Thickness\Width | 16-160-31 | 16-300-31 | 16-500-31 |
0.2-0.6 | 160 | 300 | 500 |
0.8 | 120 | 225 | 375 |
1.0 | 96 | 180 | 300 |
1.2 | 80 | 150 | 250 |
25 Series Hydraulic Precision Leveler
Table for Leveled Width Range of 25 Series (Material Q235/Yield Strength 235Mpa)
Roller Diameter | Φ25 | mm |
Width | 160,300,500 | mm |
Roller number | 31 | mm |
Rated Plate Thickness(Q235) | 0.3-1.0 | mm |
Max Plate Thickness (Q235) | 2.0 | mm |
Least Length | 50 | mm |
Leveled speed | 0-10 | m/min |
Leveled Precision(GB/T1184-1996) | H | |
Application Object | Tape coiling,sheet metals,flat parts,mirror sheet metals,etc |
Thickness\Width | 25-160-31 | 25-300-31 | 25-500-31 |
0.3-1.0 | 160 | 300 | 500 |
1.2 | 130 | 250 | 410 |
1.4 | 110 | 210 | 350 |
1.6 | 100 | 180 | 310 |
1.8 | 85 | 165 | 270 |
2.0 | 75 | 150 | 250 |
32 Series Hydraulic Precision Leveler
Table for Leveled Width Range of 32Series (Material Q235/Yield Strength 235Mpa)
Roller Diameter | Φ32 | mm |
Width | 300,500,1000,1300,1600 | mm |
Roller number | 23 | mm |
Rated Plate Thickness(Q235) | 0.5-1.5 | mm |
Max Plate Thickness (Q235) | 3.0 | mm |
Least Length | 64 | mm |
Leveled speed | 0-10 | m/min |
Leveled Precision(GB/T1184-1996) | H | |
Application Object | Tape coiling,sheet metals,flat parts,mirror sheet metals,etc |
Thickness\Width | 32-300-23 | 32-500-23 | 32-1000-23 | 32-1300-23 | 32-1600-23 |
0.5-1.5 | 300 | 500 | 1000 | 1300 | 1600 |
2 | 225 | 375 | 750 | 975 | 1000 |
2.5 | 150 | 250 | 500 | 700 | 800 |
3 | 110 | 180 | 400 | 450 | 550 |
40 Series Hydraulic Precision Leveler
Table for Leveled Width Range of 40 Series (Material Q235/Yield Strength 235Mpa)
Roller Diameter | Φ40 | mm |
Width | 500,1000,1300,1600 | mm |
Roller number | 23 | mm |
Rated Plate Thickness(Q235) | 0.6-2.0 | mm |
Max Plate Thickness (Q235) | 6.0 | mm |
Least Length | 80 | mm |
Leveled speed | 0-10 | m/min |
Leveled Precision(GB/T1184-1996) | H | |
Application Object | Tape coiling,sheet metals,flat parts,mirror sheet metals,etc |
Thickness\Width | 40-500-23 | 40-1000-23 | 40-1300-23 | 40-1600-23 |
0.6-2.0 | 500 | 1000 | 1300 | 1600 |
3 | 330 | 660 | 860 | 1060 |
4 | 250 | 500 | 650 | 750 |
5 | 200 | 400 | 480 | 550 |
6 | 160 | 280 | 360 | 450 |
50 Series Hydraulic Precision Leveler
Table for Leveled Width Range of 50 Series (Material Q235/Yield Strength 235Mpa)
Roller Diameter | Φ50 | mm |
Width | 500,800,1300,1600,2100 | mm |
Roller number | 23 | mm |
Rated Plate Thickness(Q235) | 0.8-3.0 | mm |
Max Plate Thickness (Q235) | 10 | mm |
Least Length | 100 | mm |
Leveled speed | 0-10 | m/min |
Leveled Precision(GB/T1184-1996) | H | |
Application Object | Tape coiling,sheet metals,flat parts, mirror sheet metals,etc |
Thickness\Width | 50-500-23 | 50-800-23 | 50-1300-23 | 50-1600-23 | 50-2100-23 |
0.8-3.0 | 500 | 800 | 1300 | 1600 | 2100 |
4 | 370 | 600 | 970 | 1200 | 1500 |
6 | 250 | 400 | 650 | 800 | 1050 |
8 | 180 | 300 | 480 | 600 | 750 |
10 | 130 | 230 | 380 | 480 | 600 |
63 Series Hydraulic Precision Leveler
Table for Leveled Width Range of 63 Series (Material Q235/Yield Strength 235Mpa)
Roller Diameter | Φ63 | mm |
Width | 500,800,1300,1600,2100 | mm |
Roller number | 21 | mm |
Rated Plate Thickness(Q235) | 1.2-5.0 | mm |
Max Plate Thickness (Q235) | 13 | mm |
Least Length | 100 | mm |
Leveled speed | 0-10 | m/min |
Leveled Precision(GB/T1184-1996) | H | |
Application Object | Tape coiling,sheet metals,flat parts, mirror sheet metals,etc |
Thickness\Width | 63-500-21 | 63-800-21 | 63-1300-21 | 63-1600-21 | 63-2100-21 |
1.2-5 | 500 | 800 | 1300 | 1600 | 2100 |
6 | 400 | 660 | 1080 | 1330 | 1700 |
8 | 300 | 500 | 810 | 1000 | 1300 |
10 | 250 | 400 | 650 | 800 | 1050 |
12 | 200 | 320 | 510 | 640 | 850 |
13 | 180 | 300 | 480 | 580 | 780 |
80 Series Hydraulic Precision Leveler
Table for Leveled Width Range of 80 Series (Material Q235/Yield Strength 235Mpa)
Roller Diameter | Φ80 | mm |
Width | 500,1000,1300,1600,2100,2600 | mm |
Roller number | 19 | mm |
Rated Plate Thickness(Q235) | 2-8 | mm |
Max Plate Thickness (Q235) | 20 | mm |
Least Length | 160 | mm |
Leveled speed | 0-10 | m/min |
Leveled Precision(GB/T1184-1996) | H | |
Application Object | Tape coiling,sheet metals,flat parts, mirror sheet metals,etc |
Thickness\Width | 80-500-19 | 80-1000-19 | 80-1600-19 | 80-2100-19 | 80-2600-19 |
2-8 | 500 | 1000 | 1600 | 2100 | 2600 |
10 | 400 | 800 | 1280 | 1680 | 2050 |
12 | 300 | 660 | 1060 | 1400 | 1700 |
14 | 250 | 570 | 910 | 1200 | 1485 |
16 | 200 | 500 | 800 | 1050 | 1300 |
18 | 180 | 430 | 700 | 930 | 1150 |
20 | 120 | 400 | 640 | 840 | 1000 |
100 Series Hydraulic Precision Leveler
Table for Leveled Width Range of 100 Series (Material Q235/Yield Strength 235Mpa)
Roller Diameter | Φ100 | mm |
Width | 500,1000,1300,1600,2100,2600 | mm |
Roller number | 17 | mm |
Rated Plate Thickness(Q235) | 3-10 | mm |
Max Plate Thickness (Q235) | 30 | mm |
Least Length | 200 | mm |
Leveled speed | 0-10 | m/min |
Leveled Precision(GB/T1184-1996) | H | |
Application Object | Tape coiling,sheet metals,flat parts, mirror sheet metals,etc |
Thickness\Width | 100-500-17 | 100-1000-17 | 100-1300-17 | 100-1600-17 | 100-2100-17 | 100-2600-17 |
3-10 | 500 | 1000 | 1300 | 1600 | 2100 | 2600 |
12 | 400 | 800 | 1080 | 1300 | 1750 | 2160 |
14 | 350 | 700 | 920 | 1140 | 1500 | 1850 |
16 | 300 | 625 | 810 | 1000 | 1310 | 1625 |
18 | 270 | 540 | 720 | 880 | 1150 | 1400 |
20 | 250 | 500 | 650 | 800 | 1050 | 1300 |
22 | 200 | 440 | 590 | 720 | 950 | 1180 |
24 | 180 | 400 | 530 | 660 | 875 | 1080 |
26 | 160 | 370 | 500 | 610 | 800 | 1000 |
28 | 140 | 340 | 450 | 570 | 750 | 900 |
30 | 120 | 300 | 420 | 530 | 700 | 850 |
125 Series Hydraulic Precision Leveler
Table for Leveled Width Range of 125 Series (Material Q235/Yield Strength 235Mpa)
Roller Diameter | Φ125 | mm |
Width | 500,1100,1300,1600,2100,2600 | mm |
Roller number | 15 | mm |
Rated Plate Thickness(Q235) | 5-20 | mm |
Max Plate Thickness (Q235) | 50 | mm |
Least Length | 250 | mm |
Leveled speed | 0-10 | m/min |
Leveled Precision(GB/T1184-1996) | H | |
Application Object | Tape coiling,sheet metals,flat parts, mirror sheet metals,etc |
Thickness\Width | 125-500-15 | 125-1100-15 | 125-1300-15 | 125-1600-15 | 125-2100-15 | 125-2600-15 |
5-20 | 500 | 1100 | 1300 | 1600 | 2100 | 2600 |
25 | 400 | 860 | 1040 | 1280 | 1680 | 2080 |
30 | 300 | 710 | 850 | 1050 | 1400 | 1700 |
35 | 270 | 600 | 730 | 900 | 1200 | 1450 |
40 | 240 | 520 | 640 | 800 | 1050 | 1300 |
45 | 200 | 450 | 550 | 700 | 930 | 1150 |
50 | 180 | 420 | 510 | 630 | 840 | 1040 |
160 Series Hydraulic Precision Leveler
Table for Leveled Width Range of 160 Series (Material Q235/Yield Strength 235Mpa)
Roller Diameter | Φ160 | mm |
Width | 500,1100,1300,1600,2100,2600 | mm |
Roller number | 13 | mm |
Rated Plate Thickness(Q235) | 8-30 | mm |
Max Plate Thickness (Q235) | 80 | mm |
Least Length | 320 | mm |
Leveled speed | 0-10 | m/min |
Leveled Precision(GB/T1184-1996) | H | |
Application Object | Tape coiling,sheet metals,flat parts, mirror sheet metals,etc |
Thickness\Width | 160-500-13 | 160-1100-13 | 160-1300-13 | 160-1600-13 | 160-2100-13 | 160-2600-13 |
8-30 | 500 | 1100 | 1300 | 1600 | 2100 | 2600 |
40 | 375 | 825 | 975 | 1200 | 1575 | 1950 |
50 | 300 | 660 | 780 | 960 | 1260 | 1560 |
60 | 250 | 550 | 650 | 800 | 1050 | 1300 |
70 | 200 | 460 | 540 | 675 | 900 | 1100 |
80 | 170 | 410 | 470 | 600 | 780 | 975 |
200Series Hydraulic Precision Leveler
Table for Leveled Width Range of 200 Series (Material Q235/Yield Strength 235Mpa)
Roller Diameter | Φ200 | mm |
Width | 1100,1300,1600,2100,2600 | mm |
Roller number | 11 | mm |
Rated Plate Thickness(Q235) | 10-40 | mm |
Max Plate Thickness (Q235) | 100 | mm |
Least Length | 400 | mm |
Leveled speed | 0-10 | m/min |
Leveled Precision(GB/T1184-1996) | H | |
Application Object | Tape coiling,sheet metals,flat parts, mirror sheet metals,etc |
Thickness\Width | 200-1100-11 | 200-1300-11 | 200-1600-11 | 200-2100-11 | 200-2600-11 |
10-40 | 1100 | 1300 | 1600 | 2100 | 2600 |
50 | 880 | 1040 | 1280 | 1680 | 2080 |
60 | 730 | 850 | 1050 | 1400 | 1700 |
70 | 620 | 730 | 900 | 1200 | 1480 |
80 | 550 | 650 | 800 | 1050 | 1300 |
90 | 480 | 570 | 700 | 930 | 930 |
100 | 440 | 520 | 640 | 840 | 840 |
